Name: 100 Ton Hydraulic Double-Action Stamping Press for Metal Sheets
Brand: Foshan Star Power Technology Co.Ltd
SKU: एचएसपी - 100 yd
Price: 100000.00 USD
Availability: InStock

विशेषताएं गेलरी उत्पाद विवरण एक बोली का अनुरोध

विशेषताएं

निर्दिष्टीकरण

विनिर्देश: सिंक के अनुसार

प्रमुखता देना:

100 ton hydraulic stamping press

double-action metal sheet press

hydraulic press for kitchen sink

मूलभूत जानकारी

उत्पत्ति के प्लेस: ग्वांगडोंग, चीन

ब्रांड नाम: Star Power

प्रमाणन: CU, ISO

मॉडल संख्या: एचएसपी - 100 yd

भुगतान & नौवहन नियमों

पैकेजिंग विवरण: सीवर्थी पैकिंग

प्रसव के समय: 30-50 कार्य दिवस

भुगतान शर्तें: एल/सी, टी/टी

आपूर्ति की क्षमता: प्रति वर्ष 30 सेट/सेट

गेलरी

100 Ton Hydraulic Double-Action Stamping Press for Metal Sheets

उत्पाद विवरण

High-Precision Hydraulic Double-Action Stamping Press for Metal Sheet Forming

Professional-Grade Metal Forming Equipment

The High-Precision Hydraulic Double-Action Stamping Press (Model: HSP - 100 YD) is engineered for medium to heavy-duty metal sheet processing in manufacturing environments. Combining stable pressure output, high processing precision, and efficient production capacity, this press excels at blanking, precision punching, complex bending, shaping, and deep drawing operations.

Key Advantages

100-ton nominal pressure with uniform force distribution
Double-action slider structure for complex forming tasks
Repeatability accuracy ≤0.02mm for consistent results
30% reduction in secondary processing steps
40% higher production efficiency than traditional presses
15% lower comprehensive manufacturing costs

Technical Specifications

Parameter Category	Parameter Description	Specification Value	Unit
Basic Performance	Nominal Pressure	100	Ton (T)
	Maximum Stroke Length	300	mm
	Stamping Speed (Max)	25	mm/s
	Repeatability Accuracy	≤0.02	mm
Structural Design	Structure Type	Yoke-type (Gantry)	-
	Slider Type	Double-action	-
	Worktable Size (L×W)	800×500	mm
	Worktable Thickness	80	mm
Power & Control	Power Supply Voltage	380 (Three-phase)	V/50Hz
	Rated Power	15	kW
	Control System	PLC + 10-inch HMI	-
	Hydraulic Oil Type	ISO VG 46	-
Safety & Dimension	Safety Standard Compliance	ISO 13849-1 (PLd), OSHA 1910.217	-
	Overall Dimension (L×W×H)	1600×1200×2200	mm
	Net Weight	5800	kg
	Noise Level (At 1m Distance)	≤75	dB(A)

Model Design Explanation

The model code HSP - 100 YD contains key specifications:

HSP: Hydraulic Stamping Press (product category)
100: Nominal pressure in Tons
Y: Yoke-type (gantry structure)
D: Double-action (double-slider design)

Operational Features

The press features an advanced hydraulic drive system with pressure stabilization, ensuring consistent performance. The double-action slider structure supports both synchronous and sequential operation modes, ideal for complex forming tasks like deep drawing of cylindrical containers or shaping irregular auto body parts.

Safety & Maintenance

Compliant with ISO 13849-1 (PLd) and OSHA 1910.217 standards, the press includes dual-hand safety controls and emergency stop buttons. The modular design allows easy access to critical components (hydraulic pump, filters, sensors), reducing maintenance time by 25%. The heat-treated cast iron frame ensures long service life (10+ years with proper maintenance).
